特性(Features)
◆ 適合于高密度貼裝的表面貼裝類型。
Surface mount type suitable for high density mount.
◆ 為整機產品的小型化、輕量化做出了貢獻。
It has made a contribution to the miniaturization and lightweight of the whole machine.
◆ 適應回流焊接。
Adapt to reflow soldering.
◆ 開關采用12mm 寬度載帶包裝。
The switch is packed with 12mm width carrier belt.
用途(Applications)
◆ 用于要求薄型化的。輕量化的藍牙音響設備、錄像機、通訊設備、照相機、汽車電器、手機、電腦周邊、藍牙耳機、可穿戴設備等各種操作。
For requiring thinning. Lightweight Bluetooth audio equipment, video recorders, communication equipment, cameras, car appliances, mobile phones, computer peripherals, Bluetooth headsets, wearable devices and other operations.
電性(Electrical)
◆ 額定電流(Rating): 50 mA 12 VDC
◆ 絕緣電阻(Insulation resistance):100mΩ min. 100V DC
◆ 介電強度(Dielectric strength): 250V AC for 1min
◆ 接觸電阻(Contact resistance): 100 mΩ max
◆ 操作溫度(Operating temperture range): -25℃ to +70℃
◆ 壽命(Lifetime): 100,000 Cycles min
◆ 操作力(Operating force):180±40g
◆ 行程(Travel):0.18±0.05mm
